5428200380

描述

Operational voltage AC at 50 Hz
230 V

Activation
Electrically

Activation
Electrically

Working pressure min./max.
0—16 bar

Ambient temperature min./max.
-10—50 Degree Celsius

Medium
Compressed air Compressed air

Weight
0,15 kg

The min. control pressure must be adhered to, since otherwise faulty switching and valve failure may result!
The pressure dew point must be at least 15 Degree Celsius under ambient and medium temperature and may not exceed 3 Degree Celsius .
The oil content of compressed air must remain constant during the life cycle.
Use only the approved oils from AVENTICS. Further information can be found in the ??Technical information?? document (available in the MediaCentre).
