R412014741

描述

Version
Distributor 1x

Parts
Distributor

Air supply
right

Housing
Polyamide

Sealing material
Acrylonitrile butadiene rubber

Qn 1?2
800 l/min

Qn 1?3
1000 l/min

Compressed air connection
G 1/4

Version
Non-return valve, Can be assembled into blocks

Parts
Distributor

Mounting orientation
Any

Working pressure min./max.
0—12 bar

Ambient temperature min./max.
-10—50 Degree Celsius

Medium temperature min./max.
-10—50 Degree Celsius

Medium
Compressed air Neutral gases

Weight
0,178 kg

The pressure dew point must be at least 15 Degree Celsius under ambient and medium temperature and may not exceed 3 Degree Celsius .

Material

Housing
Polyamide

Front plate
Acrylonitrile butadiene styrene

Seals
Acrylonitrile butadiene rubber
