5634695100

描述

lockable
not lockable

Switching principle
5/2

Version
Spool valve, positive overlapping

Pedal, with detent

Nominal flow Qn
1200 l/min

Compressed air connection input
G 1/4

Compressed air connection output
G 1/4

Compressed air connection type
Internal thread

Activation
Mechanical

Version
Spool valve, positive overlapping

Activation
Mechanical

Lock type
not lockable

Actuating element
Pedal, with detent

Switching principle
5/2

Sealing principle
Soft sealing

Nominal flow Qn
1200 l/min

Working pressure min./max.
-0,95—10 bar

Ambient temperature min./max.
-25—80 Degree Celsius

Medium temperature min./max.
-25—80 Degree Celsius

Medium
Compressed air

Max. particle size
50 um

Oil content of compressed air
0—1 mg/m3

Weight
1,56 kg

Dimensions
Dimensions
