0821001005

描述

Version
Poppet valve

Logic function
AND

Housing
Polyamide

Sealing material
Acrylonitrile butadiene rubber

Nominal flow Qn
80 l/min

Version
Poppet valve

Sealing principle
Soft sealing

Logic function
AND

Working pressure min./max.
1—10 bar

Ambient temperature min./max.
0—80 Degree Celsius

Medium temperature min./max.
0—80 Degree Celsius

Medium
Compressed air

Max. particle size
1 um

Oil content of compressed air
0—1 mg/m3

Weight
0,03 kg

The pressure dew point must be at least 15 Degree Celsius under ambient and medium temperature and may not exceed 3 Degree Celsius .
The oil content of compressed air must remain constant during the life cycle.
Use only the approved oils from AVENTICS. Further information can be found in the ??Technical information?? document (available in the MediaCentre).

Material

Housing
Polyamide

Seals
Acrylonitrile butadiene rubber
