0820031065

描述

Actuating control
single solenoid

Return type
With spring return

Switching principle
3/2

Version
Spool valve

Housing
Stainless steel

Sealing material
Acrylonitrile butadiene rubber

Protection class
IP65

Port size
ISO 15217, form C

Type
Plug

Nominal flow Qn
280 l/min

Compressed air connection input
G 1/8

Compressed air connection output
G 1/8

DC operating voltage
12 V

Activation
Electrically

Version
Spool valve

Activation
Electrically

Pilot
Internal

Sealing principle
metal/metal sealing

Working pressure min./max.
2—10 bar

Control pressure min./max.
2—10 bar

Ambient temperature min./max.
-10—50 Degree Celsius

Medium temperature min./max.
-10—50 Degree Celsius

Medium
Compressed air

Max. particle size
5 um

Oil content of compressed air
5—25 mg/m3

Nominal flow Qn
280 l/min

Protection class with connection
IP65

Duty cycle
100 %

mounting screws
M4 with hexagon socket

Mounting screw tightening torque
2,5 Nm

Tightening torque tolerance
??0,5

Weight
0,22 kg

The min. control pressure must be adhered to, since otherwise faulty switching and valve failure may result!
The pressure dew point must be at least 15 Degree Celsius under ambient and medium temperature and may not exceed 3 Degree Celsius .
The oil content of compressed air must remain constant during the life cycle.
Use only the approved oils from AVENTICS. Further information can be found in the ??Technical information?? document (available in the MediaCentre).

Notice: This product may only be operated with oiled compressed air.

Material

Housing
Stainless steel, hardened

Seals
Acrylonitrile butadiene rubber

Front plate
Aluminum, hard-anodized

End plate
Polyamide
