R422002212

描述

lockable
not lockable

Actuating control
single solenoid

Switching principle
3/2

Version
Spool valve

panel installation

Housing
Stainless steel

Nominal flow Qn
280 l/min

Compressed air connection input
G 1/8

Compressed air connection output
G 1/8

Compressed air connection type
Internal thread

Activation
Mechanical

Version
Spool valve

Activation
Mechanical

Lock type
not lockable

Switching principle
3/2

Sealing principle
metal/metal sealing

Nominal flow Qn
280 l/min

Working pressure min./max.
-0,95—10 bar

Control pressure min./max.
2—10 bar

Ambient temperature min./max.
-15—80 Degree Celsius

Medium temperature min./max.
-15—80 Degree Celsius

Medium
Compressed air

Max. particle size
5 um

Oil content of compressed air
5—25 mg/m3

Mounting screw
M4 with hexagon socket

Mounting screw tightening torque
2,5 Nm

Weight
See table

An example configuration is illustrated. The delivered product may thus deviate from the illustration.

Notice: This product may only be operated with oiled compressed air.

Material

Housing
Stainless steel, hardened

Seals
Acrylonitrile butadiene rubber

Actuating element
Stainless steel Polyoxymethylene Polyamide

Front cover
Steel, galvanized Steel

Threaded bushing
Brass
