R412014742

描述

lockable
lockable

Version
Ball valve

rotary switch

Housing
Polyamide

Sealing material
Acrylonitrile butadiene rubber

Qn 1?2
2600 l/min

Qn 2?3
380 l/min

Compressed air connection input
G 1/4

Compressed air connection output
G 1/4

Compressed air connection type
Internal thread

Activation
Mechanical

Version
Ball valve

Activation
Mechanical

Lock type
lockable

Actuating element
rotary switch

Working pressure min./max.
0—12 bar

Ambient temperature min./max.
-10—50 Degree Celsius

Medium temperature min./max.
-10—50 Degree Celsius

Medium
Compressed air Neutral gases

Max. particle size
25 um

Weight
0,15 kg

The pressure dew point must be at least 15 Degree Celsius under ambient and medium temperature and may not exceed 3 Degree Celsius .

Material

Housing
Polyamide

Front plate
Acrylonitrile butadiene styrene

Seals
Acrylonitrile butadiene rubber

Actuating element
Polyoxymethylene
