R412010690

描述

Parts
Condensate separator

Condensate drain
fully automatic, closed without pressure

Reservoir
Polycarbonate

Sealing material
Nitrile butadiene rubber

suitable for ATEX

Parts
Condensate separator

Mounting orientation
vertical

Certificates
suitable for ATEX

Working pressure min./max.
2—16 bar

Ambient temperature min./max.
0—50 Degree Celsius

Medium temperature min./max.
0—50 Degree Celsius

Medium
Compressed air Neutral gases

Filter reservoir volume
49 cm3

Weight
0,185 kg

To discharge condensate and oil from the compressed air network
Ideally installed at the lowest point of the compressed air network
Suitable for use in Ex zones 1, 2, 21, 22.

Material

Reservoir
Polycarbonate

Protective guard
Polyamide

Seal
Nitrile butadiene rubber
