R412005950

描述

Number of valve positions
1

Sealing material
Nitrile rubber

Subbase
Polyamide

Nominal flow Qn
700 l/min

Compressed air connection input
mm1/2?

Compressed air connection output
G 1/8

Type
Base plate for a single or double solenoid valve

Nominal flow Qn
700 l/min

Working pressure min./max.
See table

Ambient temperature min./max.
0—50 Degree Celsius

Medium temperature min./max.
0—50 Degree Celsius

Medium
Compressed air

Number of valve positions max.
1

Grid dimension
15,8 mm

Exhaust (3,5)
With directional exhaust (3/5)

Exhaust type
Ports separated

Tightening torque for mounting screws
1,1 Nm

The min. control pressure must be adhered to, since otherwise faulty switching and valve failure may result!
The pressure dew point must be at least 15 Degree Celsius under ambient and medium temperature and may not exceed 3 Degree Celsius .
The oil content of compressed air must remain constant during the life cycle.
Use only the approved oils from AVENTICS. Further information can be found in the ??Technical information?? document (available in the MediaCentre).

Material

Base plate
Polyamide

push-in fitting
Brass, nickel-plated

Seal
Nitrile rubber
