5654530000

描述

Number of valve positions
1

Housing
Die-cast aluminum

Sealing material
Acrylonitrile butadiene rubber

Working pressure min./max.
-1—30 bar

Ambient temperature min./max.
-20—120 Degree Celsius

Medium temperature min./max.
-20—120 Degree Celsius

Medium
Compressed air

Number of valve positions max.
1

Weight
See table

The min. control pressure must be adhered to, since otherwise faulty switching and valve failure may result!
The pressure dew point must be at least 15 Degree Celsius under ambient and medium temperature and may not exceed 3 Degree Celsius .
The oil content of compressed air must remain constant during the life cycle.
Use only the approved oils from AVENTICS. Further information can be found in the ??Technical information?? document (available in the MediaCentre).

Material

Housing
Die-cast aluminum, black painted

Surface
painted

Seal
Acrylonitrile butadiene rubber
