1825503856

描述

Number of valve positions
4

Subbase
Aluminum

Compressed air connection input
M5

Compressed air connection output
M5

Version
Single plug-in wiring

Working pressure min./max.
0—10 bar

Ambient temperature min./max.
-15—50 Degree Celsius

Medium temperature min./max.
-15—50 Degree Celsius

Medium
Compressed air

Grid dimension
18 mm

Direction of pneumatic port (2,4)
On the side

Exhaust (3,5)
With directional exhaust (3/5)

Mounting screw
M3

Weight
See table

The min. control pressure must be adhered to, since otherwise faulty switching and valve failure may result!
The pressure dew point must be at least 15 Degree Celsius under ambient and medium temperature and may not exceed 3 Degree Celsius .
The oil content of compressed air must remain constant during the life cycle.
Use only the approved oils from AVENTICS. Further information can be found in the ??Technical information?? document (available in the MediaCentre).

Material

Surface
anodized

Base plate
Aluminum
