1825503243

描述

Standardization
ISO 5599-1

Accessory type
type F

Frame size
ISO 1,ISO 3

Sealing material
Acrylonitrile butadiene rubber

Subbase
Die-cast aluminum

Standards
ISO 5599-1

Working pressure min./max.
-0,95—16 bar

Ambient temperature min./max.
-15—70 Degree Celsius

Medium temperature min./max.
-15—80 Degree Celsius

Medium
Compressed air

Direction of pneumatic port (1)
On the side

Direction of pneumatic port (3,5)
On the side

Exhaust (3,5)
With directional exhaust (3/5)

Exhaust type
Ports separated

Mounting screw
hexagon head

Weight
See table

The min. control pressure must be adhered to, since otherwise faulty switching and valve failure may result!
The pressure dew point must be at least 15 Degree Celsius under ambient and medium temperature and may not exceed 3 Degree Celsius .
The oil content of compressed air must remain constant during the life cycle.
Use only the approved oils from AVENTICS. Further information can be found in the ??Technical information?? document (available in the MediaCentre).

Material

Base plate
Die-cast aluminum

Seal
Acrylonitrile butadiene rubber
