0821305164

描述

Sealing material
Acrylonitrile butadiene rubber

Silencer material
Polyethylene

Compressed air connection input
G 1/8

Activation
Electrically

Activation
Electrically

Working pressure min./max.
3—6 bar

Ambient temperature min./max.
0—50 Degree Celsius

Medium temperature min./max.
0—50 Degree Celsius

Medium
Compressed air

Max. particle size
5 um

Oil content of compressed air
0—1 mg/m3

Nozzle mm
1,5 mm

Max. suction capacity
63 l/min

Air consumption at p.opt.
116 l/min

Weight
0,11 kg

Note: All data refers to an ambient pressure of 1.013 bar and an ambient temperature of 20 Degree Celsius .
The pressure dew point must be at least 15 Degree Celsius under ambient and medium temperature and may not exceed 3 Degree Celsius .
The oil content of compressed air must remain constant during the life cycle.
p.opt. = optimum working pressure

Material

Housing
Polyamide fiber-glass reinforced

Seal
Acrylonitrile butadiene rubber

Nozzle
Brass

Silencer
Polyethylene
