0821300976

描述

lockable
lockable

Version
Ball valve

rotary switch

Housing
Die-cast aluminum

Sealing material
Acrylonitrile butadiene rubber

suitable for ATEX

Qn 1?2
25000 l/min

Qn 2?3
110 l/min

Compressed air connection input
G 3/4

Compressed air connection output
G 3/4

Compressed air connection type
Internal thread

Activation
Mechanical

Version
Ball valve

Activation
Mechanical

Lock type
lockable

Actuating element
rotary switch

Sealing principle
metal/metal sealing

Certificates
suitable for ATEX

Working pressure min./max.
0—16 bar

Ambient temperature min./max.
-10—60 Degree Celsius

Medium temperature min./max.
-10—60 Degree Celsius

Medium
Compressed air Neutral gases

Weight
1,83 kg

The pressure dew point must be at least 15 Degree Celsius under ambient and medium temperature and may not exceed 3 Degree Celsius .
Suitable for use in Ex zones 1, 2, 21, 22.
A change in the flow direction (from air supply on the left to air supply on the right) occurs by rotating installation by 180?? about the vertical axis. Please see the operating instructions for further details.
Subbase (G3/4 = 1827009590, G1 = 1827009591) with block assembly kit (1827009593) is required to connect with the piping on the right.

Material

Housing
Die-cast aluminum

Front plate
Acrylonitrile butadiene styrene

Seals
Acrylonitrile butadiene rubber

Actuating element
Polyoxymethylene
